BMC PRO 832 CDX
Grup Adı/Group Name :
Arka dingil / Rear axle
Komple Adı/Assy Name :
Diferansiyel / Differantial
4K97055T
SEKIL/FIG | PARCA KODU / PART CODE | PARCA ADI | PART NAME | MIKTAR / QTY. | ACIKLAMA / REMARK |
|---|---|---|---|---|---|
1 | 40X1233 | Somun | Nut | 1 | |
2 | 1229N1730 | Rondela | Washer | 1 | |
3 | A43260M1079 | Mahruti flanşı | Drive flange | 1 | |
4 | 3264F188 | Flanş koruyucu | Deflector flange | 1 | |
5 | A1205Q2591 | Mahruti keçe | Oil seal, drive pinion | 1 | |
6 | MS2120451 | Şapkalı cıvata | Cap screw | 10 | |
7 | MWA512 | Rondela | Washer | 10 | |
8 | A1228T592 | Konik rulman, dış | Bearing cone, outer | 1 | |
9 | A1228V594 | Konik rulman, iç | Bearing cone, inner | 1 | |
10 | 1228S1267 | Rulman, mahruti | Bearing, pinion spigot | 1 | |
11 | 41X1075 | Ayna dişli tesbit cıvatası | Bolt,drive gear | 14 | |
12 | 40X1182 | Somun | Nut, drive gear | 14 | |
13 | 1229W1557 | Rondela | Washer, drive gear | 14 | |
14 | A1228X596 | Diferansiyel rulman-Sol | Bearing cone-LH | 1 | |
15 | 2214W1011 | Rulman ayar somunu-Sol | Adjusting ring-LH | 1 | |
16 | 2214X1012 | Rulman ayar somunu-Sağ | Adjusting ring-RH | 1 | |
17 | 43X1015 | Yarıklı pim | Split pin | 1 | |
18 | 42X1024 | Rondela | Washer | 4 | |
19 | 41X1018 | Şapkalı cıvata | Cap screw | 4 | |
20 | 3278W335 | İstavroz mili | Spider | 1 | |
21 | A1228Z598 | Diferansiyel rulmanı-Sağ | Bearing cone-RH | 1 | |
22 | 3107V1010 | Diferansiyel kilitleme kovanı | Clutch coller | 1 | |
23 | 41X1275 | Şapkalı cıvata | Cap screw | 12 | |
24 | 2208H944 | Conta | Gasket | 1 | |
25 | 5X1153 | O-Ring | O-Ring | 1 | |
26 | 3296A1197 | Diferansiyel kilitleme çatalı | Shift fork | 1 | |
27 | 43X1006 | Pim | Pin | 1 | |
28 | 1227P1056 | Kilitleme somunu, müşir | Nut, differantial lock, switch | 1 | |
29 | 2237D1044 | Diferansiyel kilit müşiri | Switch sensor | 1 | |
30 | 43X1015 | Yarıklı pim | Split pin | 2 | |
* | E100 | Mahruti rulman ara parça | Pinion bearing spacer | 1 | 33INCLUDE |
* | E531 | Mahruti dişli kiti | Drive gear kit | 1 | 1/2/10/11/12/13/34/38INCLUDE |
* | E188 | Dayanma rondelası | Thrust washer | 1 | 40/42INCLUDE |
* | E525 | Diferansiyel kilit kiti | Differantial lock actuator kit | 1 | 24/25/27/44/45/46INCLUDE |
* | E525 | Diferansiyel kilit kiti | Differantial lock actuator kit | 1 | 47/48/49/50/51/52/53INCLUDE |
* | E253 | Şim kiti | Shim kit | 1 | 32INCLUDE |
* | E541 | Aks dişli kiti | Diff.kit without spider | 1 | 39/40/41/42INCLUDE |
* | A13226V1010 | Pinyon yatağı kafesi-KMPL. | Pinion bearing cage-ASSY. | 1 | 8/9/31INCLUDE |
* | E542 | Aks dişli kiti, istavrozlu | Diff.kit with spider | 1 | 20/39/40/41/42INCLUDE |
* | A23235W2337 | Aks&istavroz dişli kiti-KMPL. | Differantial case & nest-ASSY. | 1 | 20/37/39/40/41/42/43INCLUDE |
* | E524 | Mahruti rulman kiti | Bearing kit | 1 | 8/9/10/14/21INCLUDE |
* | A23200K1753 | Diferansiyel taşıyıcı&kep-KMPL | Carrier & cap-ASSY. | 1 | 17/18/19/35/36INCLUDE |
1-30 | 57RS302271 | Diferansiyel-KMPL. | Diferantial-ASSY. | 1 | (4.56:1)(RS186) |
Önceki Sayfa/ Previous Page
Sonraki Sayfa/ Next Page
Sayfa/Page
81
